The CK20 slant bed CNC lathe adopts a one-piece resin sand cast bed with ultra-frequency quenching for superior rigidity. Key features include:
Control System: Syntec 7TA-E bus control with absolute encoder (no homing required)
Motion System: HIWIN Φ25 ball screws and 25mm wide guideways (28m/min rapid traverse)
Spindle Unit: A2-4 sleeve spindle driven by 2.2KW servo motor (6000 RPM max)
Tooling: 16×16mm standard tool holder, optional boring tool attachment
Automation: Compatible with auto oil-feeder and chip conveyor for unmanned production
Ideal for precision parts under Φ20mm diameter, especially for electronic connectors, instruments, and watch components, achieving surface roughness up to Ra1.6μm.
| Item/ Model | Component name and unit | CK20/25 |
| Processing range | Max turning diameter over bed(mm) | Φ250 |
| Max diameter on the pallet(mm) | Φ80 | |
| Max machining length(mm) | 100 | |
| Max bar diameter(mm) | Φ28/Φ32 | |
| Spindle through-hole diameter(mm) | Φ20/Φ25 | |
| Feed | X-axis Max travel(mm) | 500 |
| Z-axis Max travel(mm) | 200 | |
| X-axis fast movement speed(m/min) | 28 | |
| Z-axis fast movement speed(m/min) | 28 | |
| Repeat positioning accuracy(mm) | ±0.002 | |
| Guide rail form | Linear guide rail | |
| Spindle | Sleeve spindle unit(model) | A2-4（Small） |
| Spindle motor power(KW) | 4 | |
| Max speed(r/min) | 6000 | |
| Chuck size(Inch) | 4 | |
| Toolpost | Tool holder mode | Row tool |
| Tool holder specification(mm) | 16*16 | |
| Boring tool holder(mm) | Φ16 | |
| Tool table size(mm) | 350*120 | |
| Specification | Machine net weight(KG) | ≈1100 |
| Length * width * height(mm) | 1300*1180*1300 | |
| Other | Optional configuration | splicer、chip conveyor,truss manipulator,feeder |
| Socpe of application | metal disc accessories、Hardware accessories |
